Orion Elevator

Savaria Orion Elevator

The Orion elevator from ACCESS Elevator is designed with features you would expect in a high-rise elevator but built for commercial low-rise buildings. The Savaria Orion elevator was designed for limited use/limited application (LU/LA) commercial projects and is well-suited for use in educational settings, places of worship and up to 3-story professional offices.

With the features you would expect to see in a high-rise elevator such as automatic sliding doors and commercial fixtures, the Orion elevator delivers a professional appearance and a smooth ride for passengers. The Orion is a cost-effective solution to ADA-compliant accessibility that meets state and national codes for LU/LA elevators. Upgrades for the Orion include stainless steel two-speed doors to deliver a modern and sleek look.

  • High-rise style, built for low-rise applications: Affordable elevator for low-rise buildings with 1400 lb capacity and automatic door option.
  • Aesthetically appealing: Attractive call station, control panel and digital floor indicators.
  • High efficiency hydraulic drive system: Smooth ride, start and stop.
  • Variable speed pressure valve: Gradual acceleration and deceleration of cab.
  • Other standard features: Fully automatic operation, modular rail construction for easy construction, automatic cab on/off interior lighting, digital display in car operating panel, white ceiling with 4 pot lights, steel interior in choice of laminate colors.
  • Standard finishes: Standard architectural white or black steel, stainless steel car operating panel, handrail and silver color trimmed light fixtures.
  • Safety features: Emergency battery back-up for lowering and interior lighting, emergency stop and alarm buttons, emergency manual lowering, safety brakes, floor specific battery lowering, negative pressure valve.
  • Warranty: 36 months parts. Please see complete details here.
  • Applications:  Commercial (LU/LA), residential, indoors
  • Standard Capacity: 1400 lb (635 kg)
  • Maximum Travel: 300″ (7.6 m), with up to 6 stops (subject to local code requirements)
  • Nominal Speed: 30 ft/min (0.15 m/s)
  • Drive/Motor: 1:2 cable hydraulic drive, 5 hp submersed motor
  • Minimum Pit: 14″ (355 mm)
  • Minimum Overhead Clearance: 108″ (2743 mm)
  • Power Supply: 208 volt, three phase, 60 Hz, 30 amps or 240 volt, single phase, 40 amps, 60 Hz

Product Options

Many Options Available

Fully automatic operation, modular rail construction for easy construction, automatic cab on/off interior lighting, digital display in car operating panel, white ceiling with 4 pot lights, steel interior in choice of laminate colors.

Beautiful Finishes

Standard architectural white or black steel, stainless steel car operating panel, handrail and silver color trimmed light fixtures.

Safety Features

Emergency battery back-up for lowering and interior lighting, emergency stop and alarm buttons, emergency manual lowering, safety brakes, floor specific battery lowering, negative pressure valve.
